Global Excellence: Around the world, Taylor Hobson is synonymous with metrology excellence. Taylor Hobson is proud of its position as world leader in the design, development and supply of precision contact and non contact metrology equipment. Taylor Hobson operates at the highest level of accuracy within the field of surface and form metrology, delivering solutions for the most demanding applications on a global basis.
Optical metrology based on MWLI technology
• Ultra high, reproducible
accuracy ≤ ± 50 nm
• Large spherical departures
• Fast measurement speeds
Applications include: 3D form
measurement of aspheric optics ...
A versatile automat system for precision optics measurement
• Versatile 2D and 3D analysis for
spheres, aspherics and diffractives
• Designed for ease of use in the
production environment
• Form repeatability of <100 nm
and slopeangles of up to 85
degrees
Applications include: Blu Ray, hi-res
mobile phone, precision cameras...
A fully automated, fast and
accurate system for precision
optics measurement
• Fully automated one-touch optics
measurement
• Advanced software saves
production time and increases
output
• Designed for ease of use in the
production environment
Applications include: Large
diameter optics, batch testing of
multiple parts, moulded lens trees...
Precision solutions for surface finish and contour measurement
• High resolution and low noise for
optimum measurement integrity
• hoice of gauge range to suit all
applications; 1 mm, 2 mm and 5 mm
• Temperature compensation as
standard across instrument range
Applications include: engine block,
crankshafts, cylinder liners, gears,
ball screws...
Universal measurement system for contour, form and surface texture
• Single trace measurement of
surface form, dimension and
texture
• Large capacity traverse unit (200
mm) and column (700 mm)
• Complete suite of contour
analysis software, including dual
profile and gothic arch
Applications include: Fuel injectors,
precision bearings, optics ...
Portable solution for surface finish and contour measurement
• 50mm (1.97in) traverse with
straightness datum
• Automatic calibration over a
sphere ensures that radius and
form measurements are correct
Applications include: Provides portable and accurate measurement ...
HD-3D surface and film thickness optical profiler
• Film thickness measurement
from 5 microns down to 50 nm
• 4 million pixel camera for high
lateral resolution imaging
• Ultra low noise performance,
ideal for low reflectivity surfaces
Applications include: low
reflectivity surfaces, film thickness
Small footprint automated optical profiler
• Unsurpassed accuracy and repeatability, unique CCI algorithm
• Fast and easy to use, with AutoStitching, AutoFringeFind and AutoRange
• Auto analysis of 2D and 3D surfaces using the latest ISO standards
Applications include: wear testing and tribology, roughness of research samples...
Next generation interferometry at >100 microns/sec
• Scan speed up to 100 microns/second without loss of data quality
• New Claritas 20 light conditioning, increasing angle sensitivity improves data quality
• New XL option for larger parts without loss of data quality
Applications include: injector flatness, diamond turned surfaces,curved surface, optimising PV cell efficiency...
Advanced 3D non-contact high speed cone measurement
• Cone angle and roundness analysis
• Unique cone angle and roundness analysis give excellent correlation with stylus instruments
• Correlation to Talyrond instrument for roundness measurment
We also supply CCI XL series available with CCI MP, CCI MPHS and CCI HD configurations, please contact us for more information ....
Award winning tools for solar cell metrology
• Helping to improve the efficiency of solar cells
• High speed, large area high resolution measurement
• Control of trench width, depth and straightness, film thickness measurement
Applications include: trench depth,trench straightness, solar cell research...
World-leading tools for optics metrology
• Diffractive lenses can be measured quickly and automatically without contact
• Unique software specific for optics applications
• Different CCI Optics systems tailored for different applications
Applications include: aspheric and asphero-diffractive analysis, optics research...
High precision roundness roughness and contour measurement
• Ideally suited for use in production
or non-controlled environments
• Fully automated measurement
and calibration
• Active AV mounts protect the
system from external influence
Applications include: Fuel injectors,
precision bearings, calibration
standards...
Precision roundness, roughness and contour measurement
• Low noise, high accuracy for measurement integrity
• Fully automated measurement and calibration
• On-axis profile measurement
Applications include: wear testing and tribology, roughness of research samples...
A revolutionary concept in roundness inspection
• Scan speed up to 100 microns/second without loss of data quality
• New Claritas 20 light conditioning, increasing angle sensitivity improves data quality
• New XL option for larger parts without loss of data quality
Applications include: injector flatness, diamond turned surfaces, curved surface, optimising PV cell efficiency...
A three in one automated inspection system for high volume production
• Advanced multi-part measurement
• Roundness, roughness and contour
• Simplified pallet interface
Applications include: Fuel injectors, bearings, molds....
High precision instruments for large diameter components
• High load capacity up to 75 kg, high precision spindle
• Vertical straightness units of up to 900 mm
• Large diameter range up to 1000 mm and 300 mm radial arm
Applications include: Large bearings, crankshafts, cylinder heads ...
For inspection of large, heavy or complex components
• 1000 kg load X,Y table with high accuracy position control
• High accuracy spindle with large load capacity for special deep bore drop arms
• Straightness, parallelism and cylindricity measurement up to 1.5 meters
Applications include: Engine blocks, cylinder heads, crankshafts...
High speed roundness measurement systems for the bearings industry
• Speed (3 parts/minute including set-up)
• Precision (±25 nm spindle accuracy)
• Ease of use (touchscreen software)
Applications include: Bearings, compressor parts, ground, turned and honed parts...
High precision inspecition of roundness and circular geometry
• High precision air bearing spindle with roundness accuracies to +/- 0.02 um
• Talymin 5 gauge mechanism with 2 mm range
• Measurement capability to national and international standards
Applications include: Shafts, conrods, bearing components ...
A portable measurement instrument for checking surface roughness
• Large colour LCD screen
• Ready to use out of the box
• Battery life more than 2000 measurements
Applications include: Flooring, turbine blades, engineered surfaces ...
Robust and portable surface roughness testers
• Right angle measurement and 70 mm reach into bores
• Advanced parameter options to suit your application
• Anti-slip V-feet mean the system can be used on flat or curved surface
Applications include: Sheet steel, intricate
parts, small bores ...
For measuring angle, straightness, flatness, squareness, and parallelism
• Wide measurement range(1800 seconds)
• High accuracy (with High Precision variant at 0.1 seconds)
• Simultaneous dual axis operation and display
Applications include: Machine tool slide,
indexing heads, optical components...
For precision angle measurement
• For precision angle measurement
• TB100 has direct reading to 10 seconds of arc
• Digital and mechanical options available
Applications include: Setting angles on
machine tools, blades ...
For precise level and flatness measurement
• +/-600 second measuring range
• Unrivalled accuracy of 0.2 arc second over the centre measuring region
• Differential (twin level) version available
Applications include: Levelling machine beds, flatness of granite tables ...
For Straightness, Alignment, Verticality, Parallelism, Squareness and Level
• Optical and Mechanical axes aligned to within 3 seconds
• Achievable accuracy within 0.05mm at 30m (0.002in at 100ft)
• Full range of accessories available
Applications include: Bearing alignment, bore alignment ...
An industrial hardened jet engine alignment system
• Full centre and level capability with 454Kg load capacity
• Raised profile table convenient for piece part measurement and low profile stacks
• Swing away gauge heads for safe load/unload of components
Precise measurement systems for Turbine/Engine alignment
• Low profile measurement and stacking system
• Ideal for medium thrust commercial engines
• Turbine/Engines include: CFM56, CF34, PW ...
Ideally suited for small turbine components and assemblies
• Air bearing spindle master axis with radial and axial precision of < 0.125um
• Multi-gauge set up (optional8) with 4 gauge simultaneous measurement
• Gantry system with drop arm for deep bore access
Heavy duty measurement system for gas turbines
• High capacity part measurement and stacking system
• Optional gantry for deep bore measurement
• Turbine/Engines include: CF6, CFM56, PW...
.png)
For testing and alignment of large gas turbines
• 2500 lbs load capacity
• Accommodates parts up to 2.3 metres tall
• Turbine/Engines include: LM2500, LM6000, GP7000, GE90, CF6...
